E600 Mini Bullet Camera
High-Resolution Rugged Camera for Harsh Environments
The E600 Mini Bullet Camera combines high resolution and durability in a lightweight, compact design. Engineered for versatility, it is ideal for harsh environments where space and reliability are essential. Featuring 1,000 TVL resolution and true color reproduction technology, the E600 delivers clear, natural images, making it one of the best standard definition (SD) cameras on the market today.
This camera is perfect for surveillance, UAVs, marine vehicles, and industrial applications, where ruggedness and high-quality imaging are crucial.
Key Features:
- Resolution: 1,000 TVL with 1280 (H) x 960 (V) effective pixels
- Sensor: 1.3 Megapixel 1/3.2″ Sony Starvis IMX017 image sensor
- Processor: Eyenix DSP (Digital Signal Processor) for ultra-clear pictures
- Video Output: 1280 (H) CVBS Analog output
- Durable Design: Waterproof and shockproof to IP67 rating
- Lens Options: Default 3.6mm lens (other options available upon request)
- Wide Dynamic Range (WDR): Enhances video quality in variable light conditions
- 2DNR: Digital Noise Reduction for improved image quality in low-light scenarios
- Low Power Consumption: 90 mAh @ +12 VDC
- Quick Disconnect Option: Available for easier setup and maintenance
Performance Enhancements:
- Digital Noise Reduction (2DNR): Reduces artifacts in low-light environments, allowing for clearer image capture.
- Image Stabilization: Provides a stable image in high-vibration conditions, making it ideal for vehicles or aircraft.
- Ultra Low Light Sensitivity: Sony Super HAD II CCD sensor ensures excellent performance in low-light conditions (0.1 lux nativity, 0.00001 lux with sensitivity enhancement).
Applications:
- Harsh Environments: Rugged design suitable for challenging industrial, military, and commercial settings.
- Aerial and Marine: Ideal for UAVs, rotorcraft, fixed-wing aircraft, and marine vehicles.
- Surveillance: Perfect for industrial monitoring and surveillance in extreme conditions.
For more information or to request a datasheet, please contact our sales department.
High Resolution
With 600 TV Lines of resolution, the E600 is the highest resolution 1/3″ CCD bullet camera on the market. The E600 was designed specifically to record standard or high definition video with the Datatoys AirBoss Pro Digital Video Recorder, but can also be used with other recorders through a standard composite output.
Digital Noise Reduction
As light intensity decreases and the shutter speed slows, artifacts naturally appear in the video. The advanced noise filtering technology of the E600 Mini removes these artifacts and allows for clear image capture even in these low light scenarios.
Image Stabilization
Built-in electronic image stabilization provides a crisp stable image in the most vibration intense environments. After nearly a decade of developments in vibration mitigation and image stabilization, we are proud to offer one of the most stable solutions available.
Ultra Low Light Performance
Excellent low light performance is thanks to the Sony Super HAD II CCD sensor, 0.1 lux nativity and 0.00001 lux with sensitivity enhancement. Unlike other analog cameras available on the market, the E600 switches to single scan once the low light threshold is reached.
